IP66 Electric Linear Actuators Palm Sized Space Limited 2000N For Medical

Name: IP66 Electric Linear Actuators Palm Sized Space Limited 2000N For Medical
Brand: Linsheng Auto II MaxM
Price: 29 USD

Brand Name : Linsheng Auto II MaxM

Model Number : LS-PAT-83

Certification : CE

Place of Origin : CHINA

MOQ : negotiable

Price : 29-299 USD/PCS

Payment Terms : L/C, T/T, PayPal

Supply Ability : 10000 PCS per month

Delivery Time : 14 Days

Packaging Details : Paper gift box, 8 PCS/Carton

Usage : Medical Applications

Product name : Electric Linear Actuators

Voltage Related : 12/24V DC; 12/24V DC (PTC)

Max load : 2,000N (push); 1,500N (pull)

Max. speed at max. load : 6.2mm/s

Max. speed at no load : 20mm/s

Stroke : 20~300mm

Ip grade : IP66

Options : Hall sensors

Color : Black or grey

Contact Now

Small Installation Size Palm-Sized Space-Limited 2000N For Medical Applications

The LS-PAT-83 is specially designed for medical applications where a compact linear actuator is needed. The LS-PAT-83 features a very slim design with a small installation size of only stroke plus 115mm (note 1), providing manufacturers great freedom during the design process. The palm-sized motor with up to 2000N force is excellent for all kinds of space-limited products.

Main Specification Of Electric Linear Actuator

Linear Actuator	LS-PAT-83
Voltage of motor	12/24V DC; 12/24V DC (PTC)
Maximum load	2,000N (push); 1,500N (pull)
Max. speed at max. load	6.2mm/s
Max. speed at no load	20mm/s
Stroke	20~300mm
Ip grade	IP66
Output signals	Hall sensors
Color	Black or grey

Applications:

Specially designed for medical applications where a compact linear actuator is needed.

IP66 Electric Linear Actuators Palm Sized Space Limited 2000N For Medical

Drawing Of Electric Linear Actuator

Standard Dimensions (mm)

IP66 Electric Linear Actuators Palm Sized Space Limited 2000N For Medical
